PIR Sensor E-PIR14

Technical Specification:

Input Voltage：220-240V AC 50/60Hz
Output Power：1200W（incandescent lamp）,500W（ LED）
Time-Delay：10s-30s-90s-3min-7min-15min
Distance：6m.Max(＜24℃)
Light Control：3-2000LUX.adjustable
Product Size：Diameter75*Height92mm
Installation Height：Max.3.5m
Detection angle：360°
Protection Level：IP65
Operating Temperature：-10℃-40℃
Product net weight / gross weight: 132g / 150g
Product Color：White

Application Location: Indoor & Outdoor
Installation Location:Wall

Application Scenarios:
(1) Villas & Houses & Apartments & Hotels & Offices
(2) Workshop & Staircases & Corridors
(3) Public Toilets & Restrooms & Warehouses
(4) Garages & Parking Lot
