PIR Sensor SY-PIR17

INQUIRY
Input Voltage：220-240V AC 50/60Hz
Output Power：800W（incandescent lamp), 200W（ LED）
Time-Delay：10s-15min(Adjustable)
Distance：6m.Max(＜24℃)
Light Control：<10Lux~2000 Lux (Adjustable)
Product Size：Diameter40*Height58mm
Installation Height：Max.3.5m
Detection angle：360°
Protection Level：IP20
Operating Temperature：-10℃-40℃

Technical Specification:
Input Voltage：220-240V AC 50/60Hz
Output Power：800W（incandescent lamp), 200W（ LED）
Time-Delay：10s-15min(Adjustable)
Distance：6m.Max(＜24℃)
Light Control：<10Lux~2000 Lux (Adjustable)
Product Size：Diameter40*Height58mm
Installation Height：Max.3.5m
Detection angle：360°
Protection Level：IP20
Operating Temperature：-10℃-40℃
Product net weight / gross weight: 40g
Product Color：White



Application Location: Indoor
Installation Location: Ceiling recessed installationay

Application Scenarios:
(1) Villas & Houses & Apartments & Hotels & Offices
(2) Workshop & Staircases & Corridors
(3) Public Toilets & Restrooms & Warehouses
(4) Garages & Parking Lot
